最近在开发macOS远程协助功能, 需要模拟从windows传过来的键盘事件映射成macOS NSEvent, macOS上模拟事件都是底层的CoreGraphic的class,下面说下实现的片断代码.
- 导入
#import <Carbon/Carbon.h> - 创建
CGEventSourceRef事件源对象(注意它不是OC对象,声明的时候对象前边没有*,而且需要用CFRelease()释放内存). - 创建
CGEventRef使用CGEventCreateKeyboardEvent, 第三个参数true代表keydown就是键盘按键的按下状态,如果是false则代表keyup. 这里用了一个键盘kVK_ANSI_AA键作为例子 CGEventTapLocation这个是下一个函数需要的参数 应该是键盘硬件按下的键位信息(如果搞错了欢迎指正,马上修改)CGEventPost()发送NSEvent事件- 释放内存
talk is cheap, show me the code –LINUS TORVALDS
下面是演示代码
1
2
3
4
5
6
7
8
9
10
11
12
13
14
#import <Carbon/Carbon.h>
int main(int argc, const char * argv[]) {
@autoreleasepool {
CGEventSourceRef source = CGEventSourceCreate(kCGEventSourceStatePrivate);
CGEventRef A = CGEventCreateKeyboardEvent(source, kVK_ANSI_A, true);
CGEventTapLocation location = kCGHIDEventTap;
//发送事件
CGEventPost(location, A);
CFRelease(A);
CFRelease(source);
}
return 0;
}
CGEventSourceCreate()里定义了三个枚举
1
2
3
4
5
typedef CF_ENUM(int32_t, CGEventSourceStateID) {
kCGEventSourceStatePrivate = -1,
kCGEventSourceStateCombinedSessionState = 0,
kCGEventSourceStateHIDSystemState = 1
};
kCGEventSourceStatePrivate代表 专门的应用,如远程控制程序可以生成和跟踪事件源状态独立于其他进程。这些程序应该使用kCGEventSourceStatePrivate值在创建他们的事件源。
kCGEventSourceStateCombinedSessionState该状态表反映了所有事件源的组合状态发布到当前用户的登录会话。如果您的程序发布的事件在一个登录会话,您应该使用这个源状态当你创建一个事件源。
kCGEventSourceStateHIDSystemState该状态表反映了 组合硬件输入源从HID系统硬件层面发送的事件源。生成的事件。 就是外接键盘或者macbook本机键盘以及一些系统定义的按键点击事件
这里我使用的是第一个恰巧它有说明remote control
上面就是今天要分享的模拟发送系统键盘事件全部逻辑, 如有错误欢迎指正, 鄙人定当咨诹善道察纳雅言.
附* macOS ANSI码 **枚举
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
/*
* Summary:
* Virtual keycodes
*
* Discussion:
* These constants are the virtual keycodes defined originally in
* Inside Mac Volume V, pg. V-191. They identify physical keys on a
* keyboard. Those constants with "ANSI" in the name are labeled
* according to the key position on an ANSI-standard US keyboard.
* For example, kVK_ANSI_A indicates the virtual keycode for the key
* with the letter 'A' in the US keyboard layout. Other keyboard
* layouts may have the 'A' key label on a different physical key;
* in this case, pressing 'A' will generate a different virtual
* keycode.
*/
enum {
kVK_ANSI_A = 0x00,
kVK_ANSI_S = 0x01,
kVK_ANSI_D = 0x02,
kVK_ANSI_F = 0x03,
kVK_ANSI_H = 0x04,
kVK_ANSI_G = 0x05,
kVK_ANSI_Z = 0x06,
kVK_ANSI_X = 0x07,
kVK_ANSI_C = 0x08,
kVK_ANSI_V = 0x09,
kVK_ANSI_B = 0x0B,
kVK_ANSI_Q = 0x0C,
kVK_ANSI_W = 0x0D,
kVK_ANSI_E = 0x0E,
kVK_ANSI_R = 0x0F,
kVK_ANSI_Y = 0x10,
kVK_ANSI_T = 0x11,
kVK_ANSI_1 = 0x12,
kVK_ANSI_2 = 0x13,
kVK_ANSI_3 = 0x14,
kVK_ANSI_4 = 0x15,
kVK_ANSI_6 = 0x16,
kVK_ANSI_5 = 0x17,
kVK_ANSI_Equal = 0x18,
kVK_ANSI_9 = 0x19,
kVK_ANSI_7 = 0x1A,
kVK_ANSI_Minus = 0x1B,
kVK_ANSI_8 = 0x1C,
kVK_ANSI_0 = 0x1D,
kVK_ANSI_RightBracket = 0x1E,
kVK_ANSI_O = 0x1F,
kVK_ANSI_U = 0x20,
kVK_ANSI_LeftBracket = 0x21,
kVK_ANSI_I = 0x22,
kVK_ANSI_P = 0x23,
kVK_ANSI_L = 0x25,
kVK_ANSI_J = 0x26,
kVK_ANSI_Quote = 0x27,
kVK_ANSI_K = 0x28,
kVK_ANSI_Semicolon = 0x29,
kVK_ANSI_Backslash = 0x2A,
kVK_ANSI_Comma = 0x2B,
kVK_ANSI_Slash = 0x2C,
kVK_ANSI_N = 0x2D,
kVK_ANSI_M = 0x2E,
kVK_ANSI_Period = 0x2F,
kVK_ANSI_Grave = 0x32,
kVK_ANSI_KeypadDecimal = 0x41,
kVK_ANSI_KeypadMultiply = 0x43,
kVK_ANSI_KeypadPlus = 0x45,
kVK_ANSI_KeypadClear = 0x47,
kVK_ANSI_KeypadDivide = 0x4B,
kVK_ANSI_KeypadEnter = 0x4C,
kVK_ANSI_KeypadMinus = 0x4E,
kVK_ANSI_KeypadEquals = 0x51,
kVK_ANSI_Keypad0 = 0x52,
kVK_ANSI_Keypad1 = 0x53,
kVK_ANSI_Keypad2 = 0x54,
kVK_ANSI_Keypad3 = 0x55,
kVK_ANSI_Keypad4 = 0x56,
kVK_ANSI_Keypad5 = 0x57,
kVK_ANSI_Keypad6 = 0x58,
kVK_ANSI_Keypad7 = 0x59,
kVK_ANSI_Keypad8 = 0x5B,
kVK_ANSI_Keypad9 = 0x5C
};
/* keycodes for keys that are independent of keyboard layout*/
enum {
kVK_Return = 0x24,
kVK_Tab = 0x30,
kVK_Space = 0x31,
kVK_Delete = 0x33,
kVK_Escape = 0x35,
kVK_Command = 0x37,
kVK_Shift = 0x38,
kVK_CapsLock = 0x39,
kVK_Option = 0x3A,
kVK_Control = 0x3B,
kVK_RightCommand = 0x36,
kVK_RightShift = 0x3C,
kVK_RightOption = 0x3D,
kVK_RightControl = 0x3E,
kVK_Function = 0x3F,
kVK_F17 = 0x40,
kVK_VolumeUp = 0x48,
kVK_VolumeDown = 0x49,
kVK_Mute = 0x4A,
kVK_F18 = 0x4F,
kVK_F19 = 0x50,
kVK_F20 = 0x5A,
kVK_F5 = 0x60,
kVK_F6 = 0x61,
kVK_F7 = 0x62,
kVK_F3 = 0x63,
kVK_F8 = 0x64,
kVK_F9 = 0x65,
kVK_F11 = 0x67,
kVK_F13 = 0x69,
kVK_F16 = 0x6A,
kVK_F14 = 0x6B,
kVK_F10 = 0x6D,
kVK_F12 = 0x6F,
kVK_F15 = 0x71,
kVK_Help = 0x72,
kVK_Home = 0x73,
kVK_PageUp = 0x74,
kVK_ForwardDelete = 0x75,
kVK_F4 = 0x76,
kVK_End = 0x77,
kVK_F2 = 0x78,
kVK_PageDown = 0x79,
kVK_F1 = 0x7A,
kVK_LeftArrow = 0x7B,
kVK_RightArrow = 0x7C,
kVK_DownArrow = 0x7D,
kVK_UpArrow = 0x7E
};
全文完
